某体育馆泳池为1250㎡的是室内标准泳池，设计循环周期为4小时，设计流量为542.5m³/h，故采用6台11KW（5用1备）爱克循环水泵+5台Q2350过滤砂缸，使滤后池水洁净、透明；使用西美克中压紫外线HWF-420-12-再配合3台投药泵对泳池水快速高效杀菌，保持泳池水干净卫生；到了需要加热泳池水的季节，泳池采用了5台爱克B-60系列空气源热泵，对游泳池2125㎡的水进行加热。每台热泵的制热量可达250KW，无论气温如何变化，也能保证将稳定的热量输送给游泳池。从而实现无论全年全天温度如何变化，都能保持水温恒定，同时达到zui大节能效果。
Using a counter-current water circulation system, the pump sends the used pool water into the filter to remove particulate impurities in the pool water, and then returns it to the pool after subsequent disinfection and other processes.
The indoor swimming pool is a high-humidity environment, condensation and other phenomena. Bacteria, molds, and viruses will multiply, which will have a serious impact on the human body and the structure of the house. Special attention will be paid to dehumidification during the design.
In addition to hosting events, the gymnasium is also an external commercial public swimming pool. The hot water demand time is concentrated. During peak use, it must have sufficient hot water and stable water temperature, which will directly affect the image and reputation.
After the swimming pool is used for a long time, when the bottom and wall of the pool will grow algae, and the water circulation filtration system cannot remove the garbage, manual or automatic suction equipment is required to clean it.
